LN2-40.5 Indoor High-Voltage Sulfur Hexafluoride Circuit Breaker
LN2-40.5 Outdoor High-Voltage Sulfur Hexafluoride Circuit Breaker is an indoor device used in AC 50HZ three-phase systems. It can be used for protection and control in industrial and mining enterprises, power plants, and substations. And it can be used in frequent operating places. It can also be used as a contact circuit breaker and a capacitor bank circuit breaker.
Overview
LN2-40.5 Outdoor High-Voltage Sulfur Hexafluoride Circuit Breaker is an indoor device used in AC 50HZ three-phase systems. It can be used for protection and control in industrial and mining enterprises, power plants, and substations. And it can be used in frequent operating places. It can also be used as a contact circuit breaker and a capacitor bank circuit breaker.
The LN2-40.5 model can be equipped with a CT10-A spring operated mechanism or a CD10G electromagnetic operated mechanism.
Environmental conditions for use
The ambient temperature shall not exceed+40 ℃ and shall not be lower than -10 ℃.
The altitude shall not exceed 3000m.
The relative temperature should not exceed 90% (+20 ℃).
In situations where there is no risk of fire, explosion, severe pollution, chemical corrosion, or severe vibration.
