RM6-40.5 fully enclosed full insulated ges filed ring main unit is a new generaition of switchgear produced by our company as a complete set of indoor 12-40.5kV three-phase AC 5OHz equipment for recewing and distributing electric energy.It is mainly used for power transformation and transmission of medium voltage power systems such as various power plants,substations,industrial and mining enterprises,subways,civil and commercial buildings for control,protection and monitoring.It is charactenzed by reliable performance,strong adaptabllty and small size.


RM6-40.5

RM6-40.5 Fully enclosed full insulated gas filled ring main unit

Compliant standards

● GB 3906 Alternating-current metal-enclosed switchgear and controlgear for rated voltages above 3.6kV and up to and including 40.5kV

● DL/T 404 Indoor AC high voltage switchgear panel

● IEC 62271-200:2003 AC metal-enclosed switchgear and controlgear for rated voltages above 1kV and up to and including 52kV 1016001/003-0000-00 Material Procurement Standard of State Grid Corporation of China for 12kV,24kV

● 1016001/003-0000-00 Materials Procurement Standard of State Grid Corporation of China for 12KV,24kV 40.5kV High Voltage Switchgear 1016001/003-0000-00 General Technical Specifications


Service condition

● Ambient temperature:the maximum temperature is 40℃,the minimum temperature is -25℃,and the average value measured within 24h does not exceed 35℃;

● Relative humidity:the average value of relative humidity measured within 24h shall not exceed 95%,and the average value of monthly relative humidity shall not exceed 90%.

● Condensation may occur when the temperature changes rapidly during high humidity.The average value of water vapor pressure measured within 24h shall not exceed 2.2kPa,and the average value of monthly water vapor pressure shall not exceed 1.8kPa;

● Altitude:no more than 1000m;

● Seismic intensity:no more than 8 degrees;

● The amplitude of electromagnetic interference induced in the secondary system shall not exceed 1.6kV;

● The surrounding air is not obviously polluted by dust,smoke,corrosive and combustible gases,steam or salt mist.

Note:When the use conditions exceed the above provisions,the solution can be determined through consultation with the user. RM6-40.5 RM6-40.5 Fully enclosed full insulated gas filled ring main unit


Technical parameter

No.

Item

Unit

Technical parameter

1

Rated voltage

kV

12

40.5

2

Rated current

A

1250~3150

1250~2500

3

Rated frequency

Hz

50

4

Rated short-time withstand current

k/Vs

25、31.5

5

Rated peak withstand current

kA

63、80

6

Rated short-circuit current duration

S

4

7

Rated short-circuit breaking current

kA

25、31.5

8

Rated short-circuit making current

kA

63、80

9

Duration of arcing

S

0.5

10

Mechanical life

Circuit breaker

time

2000

10000

Isolating switch

3000

Grounding switch

3000

11

Electrical life of circuit breaker

time

30

12

Rated filled gas pressure(gauge pressure at 20℃)

MPa

0.05

13

Minimum functional pressure(gauge pressure at 20℃)

0.03

14

SAnnual leakage rate of SF6 gas


≤0.5%

15

Rated insulation level

Rated power frequency withstand voltage (1min)(effective)

Phase to phase,phase to ground


kV

42

95

isolating distance,vacuum opening

48

118

Rated lightning impulse withstand voltage (peak)

Phase to phase,phase to ground


kV

75

185

isolating distance, vacuum opening

85

215

16

Auxiliary

control circuit

Rated voltage

V

12

40.5

1min power frequency withstand voltage


1250~3150

1250~2500

17

Cabinet

protection grade

Cabinet housing


50

Gas fulled compartment


25、31.5

18

Category of loss of operation continuity

A

63、80

19

Temperature rise test


4

20

Main circuit resistance

1250

25、31.5

2000

2500

0.5

3150

2000

10000

21

Partial

discharge

Test voltage

kV

3000

Single insulating element

pC

3000

Complete set

30

22

Service life


0.05


RM6-40.5

RM6-40.5 Fully enclosed full insulated gas filled ring main unit

Note:

1.The rated short-circuit breaking current of 40.5kV/2000A is 31.5kA; rated short-circuit breaking current of 12kV/3150A is 31.5kA;

2.The parameters of rated peak withstand current and rated short-time withstand current of current transformer shall be assessed separately;

3.The circuit resistance refers to the measured value measured from the outgoing line of the bus coupler socket (including the bus coupler)to the outgoing line side of the cable socket (including the current device).When the bus coupler and the current device are not included,the value in the table should be subtracted by 20.


Outline and structure diagram of switchgear


1.Small bus room

2.Instrument room

3.Gas-filled compartment of main bus

4.Station disconnector

5.Operating mechanism room

6.Circuit breaker

7.Gas-filled compartment of circuit breaker

8.Cable room

9.Current transformer

10.Cable

11.CM-35 lightning arrester

12.Pressure release channel

13.Cable plug

14.Cable socket

15.Test socket plug

16.Test socket

17.Branch bus

18.Pressure relief device

19.Main bus

20.Bus coupler socket

21.Bus coupler

Note:

a(cabinet width): 600mm,800mm;

b(cabinet depth): 1420 in depth for 12kV; 1620 in depth for 40.5kV.
